Axxius 800 - Release 2.2 5-143
CLI Commands
set
set (router-lan) ipx network
Use the set (router-lan) ipx network command to specify IPX network numbers for the four
IPX LAN frame types. This enables the Axxius to Router IPX to Remote (WAN) networks,
even if an IPX server does not exist on the local LAN. Typically, the Axxius will learn its
external network number. However, if the local LAN does not have a server or if the IPX RIP
setting is set to , and you wish to Router IPX to Remote (WAN) networks, the
external network number must be defined.
Syntax: set {rtr_lan-addr} ipx network
{ieee8022|ieee8023|ethii|snap} {network}
Example: set 3:1 ipx network ieee8022 000000fl
The example will set the local LAN interface on slot 3 to IP address
192.168.202.244, with a subnet mask of 255.255.255.0.
{rtr_lan-addr}
The Router address is in the form {slot:port} or {slot "profile-name"}.
{ieee8022|ieee8023|ethii|snap}
{network}
External IPX network, specified as an 8-digit hexadecimal number.
slot The slot number (1-8) that contains the Router card.
port Port number of the Router.
"profile-name" The profile name for the Router interface. Name must be enclosed
in quotes, with a maximum length of 11 characters.
ethii Ethernet II framing
ieee8022 IEEE 802.2 framing
ieee8023 IEEE 802.3 framing
snap LLC/SNAP framing
