5-210 Axxius 800 - Release 2.2
CLI Commands
show
show (router-lan) static mac address
The show (router-lan) static mac address command displays the current list of static
MAC address entries for the LAN on the specified Router card.
Syntax: show {rtr_lan-addr} static mac address
Example: show 5:1 static mac address
SLOT 5:
Static MAC Address Settings for Adit50:
Device Name MAC Address
Axxius 66 00:E0:97:00:E9:CD
Total: 1
{tsr_lan-addr}
The Router address is in the form {slot:port} or {slot "profile-name"}.
slot The slot number (1-8) that contains the Router card.
port Port number of the Router.
"profile-name" The profile name for the Router interface. Name must be enclosed in
quotes, with a maximum length of 11 characters.
