9400 regenerative power supply module | Parameter setting

I/O terminals

Analog inputs

5.2.2

Parameter setting

Short overview of the parameters for the analog inputs:

5.2.3

Reconfiguring analog input 1 into current input

Proceed as follows to reconfigure analog input 1 into a current input:

1. Jumper terminals A1R and A1 on terminal strip X3 by means of wiring.
2. Select the corresponding current loop under

C00034

.

Open-circuit monitoring
Under

C00598

you can select an error response to an open circuit for the 4 ...20 mA current

loop.

Parameter

Information

C00034

Config. analog input 1

C00598

Resp. to open circuit AIN1

C02730/1

Analog input 1: Gain

C02730/2

Analog input 2: Gain

C02731/1

Analog input 1: Offset

C02731/2

Analog input 2: Offset

C02732/1

Analog input 1: Dead band

C02732/2

Analog input 2: Dead band

C02800/1

Analog input 1: Input signal (-16384 ≡ -100 %, 16383 ≡ 100 %)

C02800/2

Analog input 2: Input signal (-16384 ≡ -100 %, 16383 ≡ 100 %)

Highlighted in grey = display parameter
