9400 regenerative power supply module | Parameter setting
Regenerative power supply module application
Signal configuration
32
L
EDS94ARNExxxx EN 2.3 - 06/2014
Output port "LPortStatus1"
The output port LPortStatus1 is intended for the connection to a higher-level control
system.
Output port "LPortStatus2"
The output port LPortStatus2 is intended for the connection to a higher-level control
system.
Signal (Lenze setting)
Output port
Signal configuration
Status word 1
FALSE Status word 1 bit 00
C03121/1
FALSE Status word 1 bit 01
C03121/2
FALSE Status word 1 bit 02
C03121/3
FALSE Status word 1 bit 03
C03121/4
FALSE Status word 1 bit 04
C03121/5
FALSE Status word 1 bit 05
C03121/6
FALSE Status word 1 bit 06
C03121/7
FALSE Status word 1 bit 07
C03121/8
FALSE Status word 1 bit 08
C03121/9
FALSE Status word 1 bit 09
C03121/10
FALSE Status word 1 bit 10
C03121/11
FALSE Status word 1 bit 11
C03121/12
FALSE Status word 1 bit 12
C03121/13
FALSE Status word 1 bit 13
C03121/14
FALSE Status word 1 bit 14
C03121/15
FALSE Status word 1 bit 15
C03121/16
Signal (Lenze setting)
Output port
Signal configuration
Status word 2
FALSE Status word 2 bit 00
C03122/1
FALSE Status word 2 bit 01
C03122/2
FALSE Status word 2 bit 02
C03122/3
FALSE Status word 2 bit 03
C03122/4
FALSE Status word 2 bit 04
C03122/5
FALSE Status word 2 bit 05
C03122/6
FALSE Status word 2 bit 06
C03122/7
FALSE Status word 2 bit 07
C03122/8
FALSE Status word 2 bit 08
C03122/9
FALSE Status word 2 bit 09
C03122/10
FALSE Status word 2 bit 10
C03122/11
FALSE Status word 2 bit 11
C03122/12
FALSE Status word 2 bit 12
C03122/13
FALSE Status word 2 bit 13
C03122/14
FALSE Status word 2 bit 14
C03122/15
FALSE Status word 2 bit 15
C03122/16
