9400 regenerative power supply module | Parameter setting
Diagnostics & fault analysis
Error messages
246
L
EDS94ARNExxxx EN 2.3 - 06/2014
CAN module (MXI1): Faulty NMT slave configuration [0x009e0021]
CAN module (MXI1): Faulty emergency configuration [0x009f0000]
CAN module (MXI1): Node guarding error 1 ... 32 [0x00a00000 ... 0x00a0001f]
CAN module (MXI1): Faulty NMT master configuration [0x00a00020]
Response (Lenze setting printed in bold)
None System fault Fault Trouble Quick stop by trouble Warning locked Warning Information
Cause
Remedy
CANopen communication module in MXI1: A
configuration error has occurred in the network
management of the CAN slave.
• Faulty download of an Engineer or PLC Designer
project
• Invalid CAN settings according to DS301V402 in the
Engineer or PLC Designer.
• Incorrect parameterisation of node guarding or
heartbeat.
• Repeat download
• Correct CAN settings in the project and regenerate
project.
Response (Lenze setting printed in bold)
None System fault Fault Trouble Quick stop by trouble Warning locked Warning Information
Cause
Remedy
CANopen communication module in MXI1: CAN
emergency configuration is faulty.
• Faulty download of an Engineer or PLC Designer
project
• Invalid CAN emergency settings according to
DS301V402 in the Engineer or PLC Designer.
• Repeat download
• Correct CAN settings in the project and regenerate
project.
Response (Lenze setting printed in bold)
Setting:
C13612/1...32
( adjustable response)
None System fault Fault Trouble Quick stop by trouble Warning locked Warning Information
Cause
Remedy
CANopen communication module in MXI1: Cyclic node
monitoring
• CAN master has not received a response to a node
guarding telegram (remote transmission request
telegram) from node 1 ... 32 within the defined time.
• Reactivate CAN node by mains switching, restart of
the regenerative power supply module,
(
="11000") or CAN reset node.
• Reparameterise the node guarding monitoring time
or switch off monitoring.
• Reset locked error status if necessary.
Tip: Save the current parameter set before mains
switching and restarting the regenerative power supply
module (
="11").
Response (Lenze setting printed in bold)
None System fault Fault Trouble Quick stop by trouble Warning locked Warning Information
Cause
Remedy
CANopen communication module in MXI1: A
configuration error has occurred in the network
management of the CAN master.
• Faulty download of an Engineer or PLC Designer
project.
• Invalid CAN master settings according to DS301V402
and DS405 in the Engineer or PLC Designer.
• Incorrect parameterisation of node guarding or
heartbeat.
• Repeat download
• Correct CAN settings in the project and regenerate
project.
