9400 regenerative power supply module | Parameter setting
Oscilloscope
Data records
7.5 Data records
If several data records are loaded in the oscilloscope at the same time, the data record to
be displayed is selected via the Data record list field. There are three types of data records:
Online data record
The online data record is the only data record which serves to establish a connection to the
target system. When the online data record has established the connection completely, it
can communicate with the target system and is ready for use.
 In the Data record list field, the online data record is marked with a prefixed asterisk (*).
Offline data record
The offline data record is a data record already stored in the project and reloaded into the
oscilloscope or a data record imported from a file.
Merge data record
The merge data record is automatically available in the Data record list field if two or more
data records are loaded in the oscilloscope at the same time.
 In the merge data record, several curves derived from the currently loaded data records
can be overlaid, e.g. to compare signal characteristics from different recordings.
 Overlay function
( 184)
