Oscilloscope
Operation
180
L
EDS94ARNExxxx EN 2.3 - 06/2014

How to carry out automatic scaling:
1. Go to the Oscilloscope toolbar and click the icon to activate the automatic
scaling function.
2. Select the channels/variables for automatic scaling in the Select variable dialog
box.
3. Click OK.
• The dialog box is closed and the selected channels/variables are scaled
automatically.
7.4.6 Reading individual measured values
In addition to the zoom and scaling function, the oscilloscope offers a "cursor function"
that can be used to display individual measured values of a selectable channel or the
difference between two measured values.
 If the Cursor button has been clicked, the cursor function is active and two movable
vertical measuring lines are shown in the oscillograph.

How to use the cursor function:
1. Click the Cursor button.
2. Select the channel for which individual measured values are to be indicated from
the Channel list field.
3. Hold down the left mouse button and drag the red vertical measuring line to the
desired position.
• The active measuring line is represented by a continuous line, the inactive
measuring line is indicated by a dashed line.
• If you pass the mouse pointer over the inactive measuring line, this measuring
line automatically becomes active.
• The value measured at the position of the active measuring line is indicated in
the Value group box.
• The difference between the values measured at the two measuring lines is
indicated in the Difference group box.
