9400 regenerative power supply module | Parameter setting

Oscilloscope

Internal variables (oscilloscope signals)

186

L

EDS94ARNExxxx EN 2.3 - 06/2014

7.6

Internal variables (oscilloscope signals)

The system variables of the regenerative power supply module's internal control listed in

the following table can be recorded with the oscilloscope for diagnostics and

documentation purposes.

All further variables in the selection dialog of the oscilloscope are intended for closed-

loop controlled operation (in preparation).

Note!

The system variables of the internal control have a cycle offset of 2 ... 3 ms with

respect to all other variable values!

Variable

Meaning

Common.bBrakeChopperActive

Status signal "Brake chopper active"

Common.dnActualEfficiencyFactor

Current cosine phi

• Scaling: 2

30

≡ 100 %

Common.dnI2tBrakeResistor

Calculated utilisation of the brake resistor

• Scaling: 2

30

≡ 100 %

Common.dnIxtBrakeChopper

Calculated utilisation of the brake chopper

• Scaling: 2

30

≡ 100 %

Current.dnActualCurrentPhaseU

Current filter current (phase U)

Current.dnActualCurrentPhaseV

Current filter current (phase V)

Current.dnActualCurrentPhaseW

Current filter current (phase W)

Current.dnActualFilterCurrent

Current filter current

Frequency.dnActualLineFrequency

Current mains frequency

• Scaling: 2

30

≡ 4000 Hz

Phase.dnActualFilteredLinePhase

Filtered commutation angle

• Scaling: 2

30

≡ 90°

Phase.dnActualLinePhase

Unfiltered commutation angle

• Scaling: 2

30

≡ 90°

Power.dnActualPower

Current active power

• Scaling: 2

30

≡ maximum active power (

C00057

)

Voltage.dnActualDCBusVoltage

Current DC-bus voltage

Voltage.dnActualOutputVoltage

Current output voltage
