9400 regenerative power supply module | Parameter setting
Parameter reference
Parameter list | C00360
302
L
EDS94ARNExxxx EN 2.3 - 06/2014
C00360
C00361
Parameter | Name:
C00360 | CAN telegram and error counter
Data type: UNSIGNED_16
Index: 24215
d
= 5E97
h
• After power-on, counting starts with "0".
• After the maximum value has been reached, counting restarts with "0".
Display range
(min. value | unit | max. value)
0
65535
Subcodes
Information
C00360/1
Stuffing bit error counter
• More than five identical bits have been detected.
C00360/2
Format error counter
• CAN frame has not been complied with.
C00360/3
Acknow. error counter
• No device has acknowledged the telegram.
C00360/4
Bit 1 error counter
• "1" should be sent after bus arbitration, but "0" was
read.
C00360/5
Bit 0 error counter
• "0" should be sent after bus arbitration, but "1" was
read.
C00360/6
CRC error counter
• Check sum check has indicated an error.
C00360/7
Tx telegram counter
• Correctly received telegrams.
C00360/8
Rx telegram counters
• Correctly transmitted telegrams.
Read access Write access CINH PLC STOP No transfer
Parameter | Name:
C00361 | CAN bus load
Data type: UNSIGNED_32
Index: 24214
d
= 5E96
h
Switch off the device and then on again or use the device command "Reset node" (
) to reset the display of
the maximum node load (subcodes 4 ... 6).
Display range
(min. value | unit | max. value)
0
%
100
Subcodes
Information
C00361/1
Current node load in Tx direction
C00361/2
Current node load in Rx direction
C00361/3
Current node load through faulty telegrams
C00361/4
Maximum node load in Tx direction
C00361/5
Maximum node load in Rx direction
C00361/6
Maximum node load through faulty telegrams
Read access Write access CINH PLC STOP No transfer
