9400 regenerative power supply module | Parameter setting

Oscilloscope

User interface

174

L

EDS94ARNExxxx EN 2.3 - 06/2014

7.3.4

Status bar

The status messages are displayed in the status bar.

7.3.5

Trigger/cursor settings

Trigger
If the Trigger button has been clicked, the input fields for configuring the trigger conditions

will appear.

Selecting the trigger condition

( 177)

Cursor
If you click the Cursor button, you can use a vertical measuring line to read individual

measured values of a selectable channel in the oscillograph. Using a second vertical

measuring line, it is possible to indicate the difference between two measured values.

Reading individual measured values

( 180)

7.3.6

Horizontal settings

Use the Horizontal group box to select the time base and the horizontal position.

Selecting the recording time/sample rate

( 176)

7.3.7

Recording settings

Use the Recording group box to select the sample rate and start recording.

Since the measured data memory has a limited capacity, a compromise must be found

between the sample rate and the recording time that results from the time base

setting.

Selecting the recording time/sample rate

( 176)

Group box

Meaning

Channel

Channel selection

Value

Display of the value measured at the position of the active measuring line

Difference

Display of the difference between the values measured at the two measuring lines

Input field

Meaning

Time base [1/div]

Selection of time base

• The current time base setting multiplied by ten results in the recording time.

• Change the time base to stretch or compress measurements that have already been

completed.

Position

Selection of the horizontal display position

• The position value can be directly entered into the input field or selected using the arrow

buttons.

• When the arrow buttons are used and the key is pressed, you can increase the step

size to accelerate the shift.
