9400 regenerative power supply module | Parameter setting
Oscilloscope
Data records
7.5.2
Loading/importing a data record
Configurations/data records already stored can be reloaded into the oscilloscope any time,
e.g. for the overlay function.
How to load a data record from the project:
1. Go to the Oscilloscope toolbar and click .
• The Load data record dialog box appears.
2. Select the data record to be loaded from the Data record list field.
3. Click Open.
• The dialog box is closed and the selected data record is loaded.
• If the configuration to be loaded contains variables that are no longer available
in the regenerative power supply module, these variables are automatically
removed from the configuration.
How to import a data record from a file:
1. Go to the Oscilloscope toolbar and click .
• The Load data record dialog box appears.
2. Click the Import button.
3. Select the file to be imported from the workspace environment in the Open dialog
box.
4. Click Open.
• The dialog box is closed and the selected data record is imported.
• If the configuration to be loaded contains variables that are no longer available
in the regenerative power supply module, these variables are automatically
removed from the configuration.
Note!
Saved configurations should only be reused for controllers of the same type.
Otherwise wrong values might be indicated because the scaling of the
oscilloscope channels is not adapted accordingly!
