9400 regenerative power supply module | Parameter setting
"CAN on board" system bus
Implemented CANopen objects
I-1000
The CANopen index I-1000 specifies the device profile for this device. Furthermore,
additional information defined in the device profile itself can be stored here.
[6-1] Assignment of the data telegram
I-1001
Error register
 This object is related to the Lenze code C00390 .
 The error state in the data byte (U8) is bit-coded (see below table). At the moment, only
bit 0 and bit 4 of the data byte contain the corresponding information.
Index
I-1000
Name:
Device type
Subindex Default setting Display range (min. value | unit | max. value) Access Data type
0: Device type 0 0 4294967295 ro U32
8th byte 7th byte 6th byte 5th byte
Data 4 Data 3 Data 2 Data 1
High word Low word
High byte Low byte High byte Low byte
Additional information Device profile number
Index:
I-1001
Name:
Error register
Subindex Default setting Display range (min. value | unit | max. value) Access Data type
0: Error register - 0 255 ro U8
Bit Meaning when the bit is set:
Bit 0 Generic error
Bit 1 Current error (not used)
Bit 2 Voltage error (not used)
Bit 3 Temperature error (not used)
Bit 4 Communication error
Bit 5 Device-profile-specific error (not used)
Bit 6 Reserved
Bit 7 Manufacturer-specific error (not used)
