Lenze E94ARNE Regenerative power supply - Manual (Page 327)

EDS94ARNExxxx EN 2.3 - 06/2014
L
327
9400 regenerative power supply module | Parameter setting
Parameter reference
Parameter list | C01127
C01127
C01128
C01129
C01130
C01203
C01204
C01205
Parameter | Name:
C01127 | Service code
Data type: UNSIGNED_32
Index: 23448
d
= 5B98
h
This code is used internally by the device and must not be overwritten by the user!
Parameter | Name:
C01128 | Service code
Data type: UNSIGNED_32
Index: 23447
d
= 5B97
h
This code is used internally by the device and must not be overwritten by the user!
Parameter | Name:
C01129 | Service code
Data type: UNSIGNED_32
Index: 23446
d
= 5B96
h
This code is used internally by the device and must not be overwritten by the user!
Parameter | Name:
C01130 | CAN SYNC application cycle
Data type: UNSIGNED_16
Index: 23445
d
= 5B95
h
This parameter affects the influence of the sync phase position ( C01122 ) with respect to the instant of acceptance
of the synchronous PDOs by the application and the instant of transmission of the synchronous PDOs on the system
bus (CANopen).
• Taking into account an internal processing time of 150 μs, the resulting PDO delay is calculated as follows:
PDO delay = ( C01121 - C01122 + 150 μs) modulo C01130
• For the Lenze setting, the behaviour is similar to that of the previous versions, the sync phase position ( C01122 )
is calculated modulo 1000.
• The value set is rounded down automatically to integer values of 1000 μs.

Effect of C01130 on the sync phase position
Note: Setting a higher value for the application cycle than for the sync cycle time ( C01121 ) results in undefined
behaviour. The same applies if the sync phase position ( C01122 ) is set to a higher value than the sync cycle time
( C01121 ). In this case, the affected drive usually does not transmit synchronous PDOs to the system bus anymore.
 "CAN on board" system bus: sync telegram
Setting range (min. value | unit | max. value) Lenze setting
1000 μs 65000 1000 μs
 Read access  Write access  CINH  PLC STOP  No transfer
Parameter | Name:
C01203 | Counter: Brake chopper overload
Data type: UNSIGNED_16
Index: 23372
d
= 5B4C
h
Display range (min. value | unit | max. value)
0 65535
 Read access  Write access  CINH  PLC STOP  No transfer
Parameter | Name:
C01204 | Counter: Ixt overload
Data type: UNSIGNED_16
Index: 23371
d
= 5B4B
h
Display range
(min. value | unit | max. value)
0 65535
 Read access  Write access  CINH  PLC STOP  No transfer
Parameter | Name:
C01205 | Counter: DC bus overvoltage
Data type: UNSIGNED_16
Index: 23370
d
= 5B4A
h
Display range (min. value | unit | max. value)
0 65535
 Read access  Write access  CINH  PLC STOP  No transfer
