9400 regenerative power supply module | Parameter setting
Diagnostics & fault analysis
Error messages
204
L
EDS94ARNExxxx EN 2.3 - 06/2014
11534341
CAN module (MXI2) RPDO6: Telegram not received or faulty
No response
C14591/6
11534342
CAN module (MXI2) RPDO7: Telegram not received or faulty
No response
C14591/7
11534343
CAN module (MXI2) RPDO8: Telegram not received or faulty
No response
C14591/8
11665408
CAN module (MXI2) SDO client: Faulty configuration
Warning locked
-
11599872
CAN module (MXI2) SDO server: Faulty configuration
Warning locked
-
11272194
CAN module (MXI2): Basic configuration invalid
Warning locked
-
11272192
CAN module (MXI2): Bus off
Information
C14595
11403264
CAN module (MXI2): Faulty emergency configuration
Warning locked
-
11468832
CAN module (MXI2): Faulty NMT master configuration
Warning locked
-
11337761
CAN module (MXI2): Faulty NMT slave configuration
Warning locked
-
11337728
CAN module (MXI2): Heartbeat error index 1 ... 32
No response
C14613/1...32
11272193
CAN module (MXI2): Invalid node address 0
Warning
-
11337760
CAN module (MXI2): Lifeguarding error
No response
C14614
11468800
CAN module (MXI2): Node guarding error 1 ... 32
No response
C14612/1...32
8847368
CAN on board PDO manager: Configuration is faulty
Warning locked
-
8847360
CAN on board RPDO1: Telegram not received or faulty
No response
8847361
CAN on board RPDO2: Telegram not received or faulty
No response
8847362
CAN on board RPDO3: Telegram not received or faulty
No response
8847363
CAN on board RPDO4: Telegram not received or faulty
No response
8978432
CAN on board SDO client: Faulty configuration
Warning locked
-
8912896
CAN on board SDO server: Faulty configuration
Warning locked
-
8585218
CAN on board: Basic configuration invalid
Warning locked
-
8585216
CAN on board: Bus off
No response
8716288
CAN on board: Faulty emergency configuration
Warning locked
-
8781856
CAN on board: Faulty NMT master configuration
Warning locked
-
8650785
CAN on board: Faulty NMT slave configuration
Warning locked
-
8650752
CAN on board: Heartbeat error index 1 ... 32
No response
8585217
CAN on board: Invalid node address 0
Warning
-
8650784
CAN on board: Lifeguarding error
No response
8781824
CAN on board: Node guarding error 1 ... 32
No response
6881280
Code Refresh
System fault
-
6815775
Combination memory module/device not possible
System fault
-
6815769
Combination MXI1/MXI2 not possible
System fault
-
6815776
Combination of module in MXI1/device not possible
System fault
-
6815777
Combination of module in MXI2/device not possible
System fault
-
8323074
Communication error between device and device module
No response
9502734
Communication task: Standstill > 3 s
Fault
-
8323075
Communication with module in MXI1 interrupted
Information
-
8323076
Communication with module in MXI2 interrupted
Information
-
9568257
Communication with safety module interrupted
Information
-
6815758
Control card incompatible
System fault
-
6815744
Control card is defect
System fault
-
6815752
Control card is defect
System fault
-
7864328
Control card is defect (UB18 neg.)
System fault
-
7864324
Control card is defect (UB24)
System fault
-
7864326
Control card is defect (UB8)
System fault
-
7864327
Control card is defect (VCC15 neg.)
System fault
-
7864325
Control card is defect (VCC15)
System fault
-
7864329
Control card is defect (VCC5)
System fault
-
7274496
Control card: Supply voltage (24 V DC) too low
Trouble
-
7798793
CPU: Overtemperature
Warning
-
Error number
Error message
Response
Adjustable in
hex
dec
(Lenze setting)
