EDS94ARNExxxx EN 2.3 - 06/2014
L
307
9400 regenerative power supply module | Parameter setting
Parameter reference
Parameter list | C00378
C00378
C00379
C00381
C00382
C00383
Parameter | Name:
C00378 | CAN delay boot-up - Operational
Data type: UNSIGNED_16
Index: 24197
d
= 5E85
h
Time which must elapse after mains switching before the CAN NMT master puts the "Start remote node" telegram
on the bus.
• The delay time is only used when the master bit is activated (
) and the device has been restarted.
Setting range
(min. value | unit | max. value)
Lenze setting
0
ms
65535 3000 ms
Read access Write access CINH PLC STOP No transfer
Parameter | Name:
C00379 | Service code
Data type: UNSIGNED_8
Index: 24196
d
= 5E84
h
This code is used internally by the device and must not be overwritten by the user!
Parameter | Name:
C00381 | CAN Heartbeat Producer Time
Data type: UNSIGNED_16
Index: 24194
d
= 5E82
h
Time interval for sending the heartbeat telegram to the consumer(s).
• The parameterised time interval is rounded down to an integer multiple of 5 ms.
• The heartbeat telegram is sent automatically if a time interval > 0 ms is set. In this case the "node guarding"
monitoring function is deactivated.
• Mapping of the CANopen object
(see DS301 V4.02).
"CAN on board" system bus: heartbeat protocol
Setting range
(min. value | unit | max. value)
Lenze setting
0
ms
65535 0 ms
Read access Write access CINH PLC STOP No transfer
Parameter | Name:
C00382 | CAN Guard Time
Data type: UNSIGNED_16
Index: 24193
d
= 5E81
h
After the set guard time multiplied by the life time factor (
), a node guarding telegram must have been
received.
• Mapping of the CANopen object
(see DS301 V4.02).
"CAN on board" system bus: node guarding protocol
Setting range
(min. value | unit | max. value)
Lenze setting
0
ms
65535 0 ms
Read access Write access CINH PLC STOP No transfer
Parameter | Name:
C00383 | CAN Life Time Factor
Data type: UNSIGNED_8
Index: 24192
d
= 5E80
h
The life time factor multiplied by the guard time (
) results in the time during which a node guarding
telegram must have been received.
• Mapping of the CANopen object
(see DS301 V4.02).
"CAN on board" system bus: node guarding protocol
Setting range
(min. value | unit | max. value)
Lenze setting
0
255 0
Read access Write access CINH PLC STOP No transfer
