9400 regenerative power supply module | Parameter setting
"CAN on board" system bus
Process data transfer
116
L
EDS94ARNExxxx EN 2.3 - 06/2014
6.6.5.1
Parameter setting
Short overview: parameters for synchronisation via sync telegram
Sync source
serves to select the source of the synchronisation signals. There can always be only
one source for synchronising the nodes.
Sync cycle time
The sync cycle time, which can be set in
, is the time interval with which the internal
phase-locking loop (PLL) expects the sync signals. It must be set appropriately with regard
to the cycle of the synchronisation source selected in
.
Example: For the system bus the interval between two synchronisation signals has been
set with 2 ms. If the system bus is to be used as synchronisation source, a sync cycle time
of 2000 μs has to be set in
Parameter
Information
Lenze setting
Assignment
Value Unit
Sync
master
Sync
slave
CAN SYNC Rx identifier
128
CAN SYNC Tx identifier
128
CAN SYNC transmit cycle time
0 ms
Sync source
OFF
Sync cycle time
1000 μs
Sync phase position
400 μs
Sync tolerance
0 μs
Sync-PLL increment
109 ns
Sync application cycle
1000 μs
Note!
If the synchronisation is carried out via the system bus, only integer multiples of
1000 μs make sense for the setting in
.
