EDS94ARNExxxx EN 2.3 - 06/2014
L
277
9400 regenerative power supply module | Parameter setting
Parameter reference
Parameter list | C00053
C00053
C00054
C00055
C00057
C00061
C00062
C00063
Parameter | Name:
C00053 | DC-bus voltage
Data type: UNSIGNED_32
Index: 24522
d
= 5FCA
h
Display range
(min. value | unit | max. value)
0
V
2147483647
Read access Write access CINH PLC STOP No transfer
Parameter | Name:
C00054 | Line current
Data type: UNSIGNED_32
Index: 24521
d
= 5FC9
h
Display range
(min. value | unit | max. value)
0.00
A
500.00
Read access Write access CINH PLC STOP No transfer
Scaling factor: 100
Parameter | Name:
C00055 | Phase currents
Data type: INTEGER_32
Index: 24520
d
= 5FC8
h
Display range
(min. value | unit | max. value)
-500.00
A
500.00
Subcodes
Information
C00055/1
Phase current zero system
C00055/2
Phase current phase U
C00055/3
Phase current phase V
C00055/4
Phase current phase W
Read access Write access CINH PLC STOP No transfer
Scaling factor: 100
Parameter | Name:
C00057 | Maximum effective power
Data type: INTEGER_32
Index: 24518
d
= 5FC6
h
Display range
(min. value | unit | max. value)
-1000.0
kW
1000.0
Read access Write access CINH PLC STOP No transfer
Scaling factor: 10
Parameter | Name:
C00061 | Heatsink temperature
Data type: INTEGER_32
Index: 24514
d
= 5FC2
h
Display range
(min. value | unit | max. value)
-200
°C
200
Read access Write access CINH PLC STOP No transfer
Parameter | Name:
C00062 | Temperature inside the controller
Data type: INTEGER_32
Index: 24513
d
= 5FC1
h
Display range
(min. value | unit | max. value)
-200
°C
200
Read access Write access CINH PLC STOP No transfer
Parameter | Name:
C00063 | Filter temperature
Data type: INTEGER_32
Index: 24512
d
= 5FC0
h
Display range
(min. value | unit | max. value)
-200
°C
200
Read access Write access CINH PLC STOP No transfer
