9400 regenerative power supply module | Parameter setting
"CAN on board" system bus
Implemented CANopen objects
152
L
EDS94ARNExxxx EN 2.3 - 06/2014
I-1011
Loading of Lenze setting.
Corresponds to the device command
= "0: Load Lenze setting".
This command serves to reset the parameters of the active application to the Lenze
setting stored in the firmware.
Reading subindex 1
[6-5]
Assignment of the data telegram (reading)
Writing to subindex 1
In addition to index and subindex, the telegram data must include the signature "load"
(ASCII characters; ISO 8859) to start the loading of the Lenze setting.
A response according to the specification DS301 V4.02 occurs when a wrong identifier
is used for writing.
[6-6]
Assignment of the data telegram (writing)
Index:
I-1011
Name:
Restore default parameters
Subindex
Default setting
Setting range (min. value | unit | max. value)
Access
Data type
0: Highest subindex supported
1
- (read access only)
ro
U32
1: Restore all default parameters
-
0
4294967295 rw
U32
Subindex
Meaning
Reading
Writing
0
Max. number of supported subindexes: 1 -
(A write attempt results in the error
message 0x06010002.)
1
Loading of all parameters is possible.
Loading of Lenze setting.
8th byte
7th byte
6th byte
5th byte
Data 4
Data 3
Data 2
Data 1
Bit 31 ... bit 1
Bit 0
0
0/1
Bit
Setting
Bit 0
0 Loading of parameters not possible.
1 Loading of parameter possible (Lenze).
8th byte
7th byte
6th byte
5th byte
Data 4
Data 3
Data 2
Data 1
"d" = 0x64
"a" = 0x61
"o" = 0x6F
"l" = 0x6C
