5-1 IM WX104-01E
Conf
gur
ng the DX100/DX200/MV100/MV200
1
2
3
4
5
6
7
8
9
Index
5.1 Startng the Confgurator
The following two types of files can be opened using the Configurator:
Settings cannot be entered on the DX1000/DX2000.
CONFIG fle
This is the file located in the DX/MV folder. It allows a direct view of the setup data of the
DX100/DX200/MV100/MV200. Only one CONFIG file exists in one DX/MV folder.
You can change the setting on the Configurator, but the file cannot be saved.
Setup data fle (*.PNL)
This is the file that is saved to the PC such as to the DAQ Desktop. You can change the
settings on the Configurator and save the file and create new setup data.
The Configurator can transmit and receive the setup data, change the setup data, and
create new setup data. It can configure the following style numbers of DX and MV.
DX/MV Style1 Style2 Style3 Style4
DX100
DX200
MV100
MV200
Copyng the Setup Data to the DAQ Desktop
You can copy the CONFIG file to the DAQ Desktop by dragging and dropping the
CONFIG icon of the DX/MV folder onto the DAQ Desktop.
The extension of the file that is copied becomes [PNL].
Chapter 5 Confgurng the DX100/DX200/MV100/MV200
