6-26
IM WX104-01E
Match Tme Tmer
Set the time match condition used in event action. You can set the time condition that
is used by the event action function. The table below shows the number of match time
timers supported by the DX1000 and DX2000.
Model
Number of Match Tme Tmers
Models without the multi batch function
(/BT2 option)
4
Models with the multi batch function
(/BT2 option; release number 3 or later)
12
• Knd
Day
Set the time match condition of a day.
Week
Set the time match condition of a week.
Month Set the time match condition of a month.
Year
Set the yearly time match conditions (release number 3 or later).
Set the items with check marks in the following table depending on the Kind setting.
Daily
Weekly
Monthly
Year
Month
Day
Week
Hour:Minute
Kind
Setup Item
• Day
Set the day.
• Weekday
Set the day of the week.
• Hour:Mnute
Set the time in the range of 00:00 to 23:59.
• Tmer acton
Settngs
Descrpton
Single
Executes the action once when the condition is met.
Repeat
Executes the action at every specified time.
6.4 Enterng General Settngs
