7-58
IM WX104-01E
7.7
Checkng the System Confguraton and
Intalzng Setup Data
Checkng the System Confguraton
On the MV1000/MV2000 Configurator of the connected MV1000/MV2000, selecting
[System Configuration] from the [System] menu opens the [System Configuration] dialog
box. You can only view the system configuration on this [System Configuration] dialog
box.
2. The [System Configuration]
dialog box opens.
1. Select [System] -
[System Configuration].
Note
If you select [System Configuration] from the [System] menu on the MV1000/MV2000
Configurator that was opened by double-clicking the setup data file on the DAQ desktop or
loading the setup data, a [System Configuration] dialog box in which you can change the
system configuration opens. If the system configuration is changed in this dialog box and the
[OK] button is clicked, a message “System Configuration is changed Input&Data are Initialized”
appears. Click the [OK] button to initialize the data.
Intalzng the Setup Data
To initialize the settings, select [Initialize] from the [Setting] menu on the MV1000/
MV2000 Configurator.
2. The [initialize confirmation]
dialog box opens.
1. Select [Setting] - [Initialize].
3. Execute the initialization.
