When obtanng the IP address from DHCP
• DHCP
Set [DHCP] to [ON].
• DNS accesson
To automatically obtain the DNS server address, select [ON]. Otherwise, select [OFF].
If you select [OFF], you must set the IP address of the DNS server.
• Host-Name Regster
To automatically register the host name, select [ON].
• Host Name
Set the MV1000/MV2000’s host name using up to 64 alphanumeric characters.
• Doman Name
Set the network domain name that the MV belongs to using up to 64 characters.
• Server Prmary, Server Secondary (not necessary when DNS accesson
s enabled)
Register up to two IP addresses for the primary and secondary DNS servers.
• Doman Prmary, Doman Secondary
Set up to two domain suffixes: primary and secondary.
Keep Alve
To disconnect when there is no response to the test packets that are periodically sent,
select [ON]. Otherwise, select [OFF].
Tme out
To use the application timeout function, select [ON]. Otherwise, select [OFF]. If you
select [ON], a [Timeout time] is displayed.
• Tmeout tme (mn.)
Set the timeout value between 1 and 120 (minutes).
Checkng the communcaton status
The Ethernet communication status can be confirmed with the LED lamp that is provided
on the Ethernet connector on the MV1000/MV2000 rear panel or the [Ethernet link] that
is shown at the upper right of the basic setting screen.
7.5 Enterng Basc Settngs
