8 displaying the tlog file, Displaying the tlog file, 8 displaying the tlog file -21 – Yokogawa DAQWORX User Manual
Page 83: Displaying the tlog file -21, 8 dsplayng the tlog fle

4-21
IM WX104-01E
D
splay
ng Data w
th the Data V
ewer
1
2
3
4
5
6
7
8
9
Index
4.8
Dsplayng the TLOG Fle
Dsplayng the TLOG Fle
DX/MV/CX folder
1. Double-click the TLOG file icon.
2. The file opens.
Open a file (section 4.1)
Save display conditions (section 4.9)
Section 4.1
Section 4.11
File information (section 4.1)
Turn ON/OFF flags ([View] - [Flags])
Waveform label (select channel No. or tag)
Timer No. selection tab
Scroll the screen (left and right)
Date display
Time display
Data No.
