6-38 IM WX104-01E
• Key Securty
Settngs Descrpton
Login Enables only registered users to operate the DX using keys. The [User
registration] is displayed in the [Basic Setting] tab.
Keylock Enables the key lock function. Set the key lock function in the [Basic Setting]
tab.
OFF Disables the security functions.
• Comm. Securty
Settngs Descrpton
Login Enables only registered users to operate the DX via communications. The
[User registration] is displayed in the basic setting mode menu.
OFF Disables the security functions.
• Auto Save
Settngs Descrpton
ON Automatically saves the measured data to the CF card.
OFF Does not automatically save the data. Save the measured data manually to
the CF card or USB flash memory (/USB1 option).
• Meda FIFO
You can select this with DX main unit firmware version 2.0x or later.
This is valid only when [Auto Save] is [ON].
Settngs Descrpton
ON If there is no more free space on the CF card, the oldest file is deleted, and
the newest file is saved.
OFF If there is no more free space on the CF card, the measured data is not saved
to the CF card.
Opton
• Value on Error
Specify whether to set the display for a computation error to [+Over] or [–Over].
• Overflow Sum, Ave
Specify how to handle
overflow data when it is detected in the SUM or AVE
computation of TLOG or CLOG. This setting is also applied to report generation.
Settngs Descrpton
Error Sets the computed result to computation error.
Skip Discards the overflow data and continues the computation.
Limit Uses a limit value in place of the overflow data and continues the
computation.
• Overflow Mn, Max, P-P
Specify how to handle overflow data when it is detected in the MAX, MIN, or P-P
computation of TLOG or CLOG. This setting is also applied to report generation.
6.5 Enterng Basc Settngs
