Page 104

5-8
IM WX104-01E
Click to display the setting item selection screen,
then select the setting items you wish to copy.
The setting item selection screen that opens
when you click the Details button.
The names of setting items are displayed.
Paste to the copy destination
Read the copy source setting
Copyng and Pastng
1. Select the copy source number, then click the Copy button.
* You can drag to select multiple copy source numbers.
2. Select the copy destination number, then click the Paste button.
* You can drag to select multiple copy destination numbers. The specified settings are copied
and pasted.
Settng One Channel at a Tme
2. The channel setting
dialog box opens.
3. Select the tab of the item
to be configured.
4. After setting the
items, click here.
1. Double-click the
channel you wish to set.
Apply the settings.
Update according to the changes
in the [Meas] sheet.
The items in the measurement channel tab can be configured for each channel. The
items that are configured are the same as those configured on the spreadsheet. For
details, see the page corresponding to the item.
5.2 Settng the Measurement Channels
