Page 61: Turn on/off the lnk
3-26
IM WX104-01E
3.9
Pausng the Montor and Turnng ON/OFF the
Lnk
Pausng the Montor
Click here ([File] - [Pause]).
The display data are continuously acquired even when the monitor is paused. Thus,
when the monitor is restarted, the measured values acquired while the monitor was
paused are also displayed.
The monitors that pause are those on the same connection as the active window.
Turn ON/OFF the Lnk
Click here ([File] - [Link]).
You can specify whether or not to link the group display operation of the data monitor (trend
monitor, color graphics monitor, numeric monitor, meter monitor, and circular monitor) of
the same connection.
When the link is turned ON and the displayed group is changed in one Data Monitor, the
displayed groups in all monitors that have the link turned ON also change.
Note
• As default, all monitor links are turned ON.
• There is no link setting for the alarm monitor, because it displays all groups.
