6-42 IM WX104-01E
Alarm acton
• No Loggng
Select [ON] to hide alarm indication. The [Detect] setting is enabled in the Measure
channel, Math channel, Ext channel tab(s).
This function disables the alarm indicator and the logging of alarm events to the alarm
summary. It also disables the display of alarms by the alarm annunciator (release
number 3 or later).
• Annuncator mode and Sequence (Release number 3 or later)
To use the annunciator function, select [ON] and set the sequence.
Settngs Descrpton
ISA-A-4 A no lock-in sequence.
ISA-A A lock-in sequence.
ISA-M A double lock-in sequence.
• Tme off color (Release number 3 or later)
The annunciator window display color when no alarms are activated. You can select
[White] or [Green].
Alarm dsplay (Release number 3 or later)
• Level
When multiple alarms occur, the DX gives higher priority to the display of alarms with
higher levels.
Settngs Descrpton
1>2>3>4 The order of alarm level preference, from highest to lowest preference, is 1, 2,
3, 4.
1>4>2>3 The order of alarm level preference, from highest to lowest preference, is 1, 4,
2, 3.
1>4>3>2 The order of alarm level preference, from highest to lowest preference, is 1, 4,
3, 2.
• Alarm 1, Alarm 2, Alarm 3, and Alarm 4
You can set the alarm color for each alarm level. It is easy to understand what
processes are taking place when alarms occur if you associate an alarm’s color with
its level. This setting applies to all channels.
6.5 Enterng Basc Settngs
