Conf
gur
ng the MV1000/MV2000
Bar Graph Drecton
Select Bar graph direction.
Brghtness
Select a value from 1 to 6 (2 by default). Larger the value, brighter the display becomes.
Backlte Save Mode
Settngs Descrpton
OFF Disables the backlight saver.
Dimmer Dims the display if there is no operation for a given time.
Timeoff Turns the backlight OFF if there is no operation for a given time.
Backlght Saver Tme
Select a value from 1 min to 1 h. If the specified time elapses without any key operation
or alarm occurrence, the LCD backlight switches to the specified mode.
Backlght Restore
Settngs Descrpton
Key The backlight returns to the original brightness when a key is pressed.
Key&Alarm The backlight returns to the original brightness when a key is pressed or
when an alarm occurs.
Trend Background
Set the background color of the operation screen to White (default setting) or Black.
Hstorcal Trend Background
Select the background color of the historical trend display from the following:
Settings: White, Black (default setting), Cream, and Lightgray
Scroll Tme
Set the switching interval from the available settings between 5 s and 1 min. The groups
switch in ascending order.
Jump Default Dsplay
Returns to a preset display if there is no key operation for a specific time.
Settngs Descrpton
1min to 1h Time until switching the display.
OFF Disables the function.
HISTORY Key Operaton
• Operaton
Settngs Descrpton
History Switches to the historical trend display when the key is pressed.
Favorite Switches to the favorite display that you registered when the key is pressed.
• Group Dsplay
Settngs Descrpton
Current Displays a favorite display in the current group.
Saved Displays a favorite display in the group that was selected when you registered
the favorite display.
• Tme Axs Zoom
Settngs Descrpton
Current Displays a favorite display at the current time axis zoom rate.
Saved Displays a favorite display at the time axis zoom rate that was selected when
you registered the favorite display.
7.4 Enterng General Settngs
