2-8 IM WX104-01E
Click here (send a trigger)
Trgger
Sends the trigger signal used to store the event data to the internal memory. The trigger
is valid when the mode used to store the event data to the internal memory of the DX,
MV or CX is [Trigger] or [Rotate], trigger type is set to key trigger ([Manual Trigger] is set
to [ON], see page 5-17, 6-24, 7-23, or 8-41) and the DX, MV or CX is in the trigger-wait
condition after you press the Start button. The trigger button is invalid during all other
operations.
2.2 Startng and Stoppng Data Acquston on the DX/MV/CX, Send a Trgger
