Page 310

8-53
IM WX104-01E
1
2
3
4
5
6
7
8
9
Index
Conf
gur
ng the CX1000/CX2000
Settng One Channel at a Tme
2. Click the tab of the item
to be set.
3. After setting the
items, click here.
1. Double-click the channel
to set to open the Channel
Settings dialog box
Applies the settings.
Update according to the changes
in the [Meas] sheet.
The items of the [Meas] tab can be set for each channel. The items set here are the
same as the ones in the [Meas] tab of the Hardware Configurator. For details, see the
page corresponding to the item.
8.8 Measurement Channels Settngs
