Page 129

6-2
IM WX104-01E
Startng the Confgurator
To create a new setup data file apart from the connected DX1000/DX2000, double-click
the CONFIG icon on the DAQ desktop or choose Fle > New in the DX1000/DX2000
Configurator to display the System Configuration dialog box. Configure the system, then
open the DX1000/DX2000 setting screen.
DX1000/DX2000 folder
1. Double-click here.
2. The DX1000/DX2000 Configurator
opens.
Print (section 6.9)
Display the version information of the Configurator
Scroll the screen (left and right)
Menu bar
Toolbar
Scroll the
screen
(up and down)
6.1 Startng the Confgurator
