Regsterng the channel
1. Click one.
2. The [Channel No.] dialog box opens.
3. Click one.
Types of Y-axs and turnng ON/OFF the Y-axs
Select linear or logarithmic by clicking the Y-axis display area. If [Multi-Axis Zone] (page
3-7, Setting the Y-axis) is selected, you can select whether or not to display the Y-axis.
The Y-axis of the waveform for which the check box is shown in [blue] will be displayed.
Scale (dsplay range)
The range of minimum and maximum values is from -10
16
to 10
16
, excluding the decimal
point.
Click the scale value display area to enter values.
Zone (dsplay poston)
The range is as follows:
• Minimum value: 0 to 99%
• Maximum value: 1 to 100%
Specify the waveform display position by taking the bottom edge of the waveform display
area of the trend display screen to be 0% and the top edge to be 100%. Click the zone
display area to enter values.
Trp lne
Two trip lines (trip 1 is red, trip 2 is blue) can be set for each waveform. Only the trip
lines of the active waveform are displayed on the trend screen. However, on the auto
zone display screen (“Setting the Y-axis” on page 3-7), the trip lines of all displayed
waveforms that are checked are displayed.
When the monitor is paused (section 3.9), you can change the position of the trip line by
dragging it.
3.2 Dsplayng the Trend
