Vew Group
Set the screens that will be displayed in the 4 panel display. This function is for the
MV2000 only.
With revision R7.21 or later, you can open a settings dialog box for any view group by
double-clicking its number.
View group number
Select the group to be displayed
Selectable view types
Select the type of views to be displayed or drag
and drop the view icons
Enter the view group name
Group Name
Up to 16 characters can be entered for the group name.
Vew Knd
The view group is made up of four screens. Select the type of screen to display in each
screen.
Vew Group
Up to four view groups can be registered.
7.4 Enterng General Settngs
