8-30
IM WX104-01E
8.6
Program Control Related Setup Operatons
Turn ON/OFF Program Control
Program control can be turned ON and OFF using the internal loop setting of the control
function basic settings.
Click the Setup tab then select [Internal Loop] from the list that appears on the left of the
screen. Or, you can select the items by choosing Control Settings > Setup[Basic] Setting
> Internal Loop.
Select the loop number
Click this tab
Program control ON/OFF
(For every 2 loops on Style 2 or earlier
For every loop on Style 3 or later)
Note
You must first turn ON program control to carry out the program control related settings below.
