5-12 IM WX104-01E
5.4 Confgurng the Settngs
Screen Dsplay
Select this tab Select the time per 1 division
Select the display format of
the trend and bar graph
Recover by a key operation
Recover by a key operation or alarm occurrence
The screen saver function
is activated, when there is
no key operation or alarm
occurrence for the
specified time period.
If you selected MV100 in the “System Configuration” dialog box, “User key” on the “Setting”
page will not be displayed.
Dsplay update nterval
You can select the display update interval from 1 min/div, 2 min/div, 5 min/div, 10 min/div,
20 min/div, 30 min/div, 1 h/div, 2 h/div, and 4 h/div. In addition to these selections, 15
sec/div and 30 sec/div can also be selected on the MV102, MV104, MV204, and MV208
when the style number is greater than or equal to 3.
Auto save nterval
The auto save interval can be specified when the [Save] is set to [Auto] (see page 5-17)
and the data type is set to [DISPLAY] or [EVENT&DISP] in the memory sample section
of the setup tab.
Auto scroll tme
This is the time period used to automatically switch the displayed group. It can be
specified when the style number of the DX or MV is greater than or equal to 2.
