Settng the Vew Group (DX200, MV200 Only)
Click here (also selectable from [Setting] - [SET [Regular] Setting])
Enter the view group name
Select the type of screen to be displayed
Select the group to be displayed
Type of screens
available
or drag & drop
Vew group
Up to four view groups can be registered.
Group Name
Up to 16 characters can be entered for the group name. The specified group name
appears as a sub menu of the [4 Panel] display of the DX200/MV200.
Vew Knd
The view group is made up of four screens. Select the type of screen to display in each
screen.
User Key (DX100, DX200 and MV200 Only), Daylght Savng, Batch (Opton,
When the Style Number s Greater than or Equal to 2)
Click either one (also selectable from [Setting] - [SET [Regular] Setting])
Select the function to be assigned to the USER key
Select either one
Enter using up to
16 characters.
Enter the value
in the range
from 0 to 9999
5.4 Confgurng the Settngs
