4-19 IM WX104-01E
D
splay
ng Data w
th the Data V
ewer
1
2
3
4
5
6
7
8
9
Index
3. Click here([Ctrl Mode...])
For the alarm list or the event list, click a label to sort using the label. The first click will
sort the list in the ascending order; the second click will sort the list in the descending
order.
Note
If you drag on the “Alarm List” display screen, a pointer is displayed. The cursor on the
waveform display, circular display, numerical display, and cursor value display are not
synchronized to this pointer.
Convertng and outputtng the alarm or mark lst
The Alarm or Mark List can be converted to ASCII, Lotus, and Excel formats.
1. Click here([Convert]-[Alarm to] or [Mark to])
2. The [Alarm List] or [Mark List] dialog box opens.
3. Click here.
6. Click here.
4. The [Save As] dialog box opens.
Enter the file name.
Select one.
5. Set the items and
click here.
4.6 Lstng Alarms and Marks and Convertng the Lst
