Page 64

4-2
IM WX104-01E
Fles that launch the Data Vewer
The Data Viewer starts by opening the following three types of files:
•
: Display data file (*.dds and *.cds (CX), *.DAD (DX1000/DX2000))
•
: Event data file (*.dev and *.cev (CX), *.DAE (DX1000/DX2000))
•
: TLOG file (*.dtg)
•
: Link setting file (*.ldx)
•
: Hourly repot file (*.dhr)
•
: Daily repot file (*.ddr)
•
: Weekly repot file (*.dwr)
•
: Monthly repot file (*.dmr)
•
: Report file (*.DAR)
•
: Manual sampling file (*.dmn, *.DAM)
Toolbar, search bar, and status bar
Clicking [View] - [Toolbar], [Search Bar], or [Status Bar] from the menu bar displays the
corresponding bar in the window. The bar will disappear if the check is removed.
Openng the Fle by Specfyng ts Locaton
1. Click here ([File] - [Open]).
3. Select the desired file
and click the [Open]
button.
Supplementary Info. tab
Batch Info. tab
2. The [Open] dialog box opens.
Information about the selected file
You can open a file by specifying the location. You cannot specify the internal memory or
the external storage medium of the RECORDER.
Checkng the nformaton about the loaded fle
You can check the information about the active data file by selecting [Information] - [About
Document].
4.1 Startng and Extng the Data Vewer
