ng the MV1000/MV2000
Partal (Partal Expanded Dsplay)
Bound poston (%)
Set the boundary for the partial expanded display. The range is from 1 to 99%.
Boundary
Set the value that is to be the boundary between the reduced section and the expanded
section in the range of “minimum span value + 1 digit to maximum span value – 1 digit.”
For channels that are set to scaling, the selectable range is “minimum scale value + 1
digit to maximum scale value – 1 digit.”
Example: Input range: –6 V to 6V. Bound position: 30. Boundary: 0
The –6 V to 0 V range is displayed in the 0% to 30% range, and the 0 V to 6
V range is displayed in the 30% to 100% range.
The conditions used to set the boundary vary depending on the measurement and
computation channels as follows:
• Measurement channel
When SCALE and SQRT are not used: Span L < boundary < span U
When SCALE and SQRT are used: Scale L < boundary < scale U
• Computation channel
Span L < boundary < span U
Note
For the MV1000/MV2000, this is when [Partial] is turned [ON] under [Detail Setting] in the [Basic
Setting] tab.
Color (Dsplay Color)
You can select the display color of each channel from 24 colors.
Green Band
Displays a specified section of the measurement range using a color band on the scale.
This setting is common with the bar graph display.
Regon (Band area)
Settngs Descrpton
Inside Displays the area inside using the color band.
Outside Displays the area outside using the color band.
OFF Disables the function.
Color
Set the display color.
L and U
Specify the display position. Set a value within the span or scale range.
L: Lower limit of the area.
U: Upper limit of the area.
7.2 Settng the Measurement Channels, Ext. Channels
