8-52
IM WX104-01E
Graph
Dvsons
Select the number of bar graph divisions.
Bar graph
Select the reference position of the bar graph. Selecting [Center] when the bar graph is
vertical produces no effect.
It is set to [Normal] when the data is checked.
Scale
When using scale display on the trend screen, select the scale display position.
Partal
Expand (%)
Set the boundary for the partial expanded display. The range is 1 to 99%.
Boundary
The conditions used to set the boundary vary depending on the measurement and
computation channels as follows:
• Measurement channel
When SCALE and SQRT are not used: Span L < boundary < span U
When SCALE and SQRT are used:
Scale L < boundary < scale U
• Computation channel
Span L < boundary < span U
For details, refer to the CX User’s Manual (IM 04L31A01-01E or IM 04L31A01-03E).
Note
The partial expansion settings take effect when the partial expansion function is set to [Use] in
the [Aux] section of the [Setup] tab.
Dsplay Color
You can select the display color of each channel from 16 colors.
Copyng and Pastng Setup Data
You can copy the setup data of one channel or more to other channels. Use the following
procedure to copy and paste.
1. Click the source channel number that you want to copy. To select many channels,
click the first source channel, then drag over all the channels that you want to copy.
2. Click the [Copy] button at the bottom of the window.
3. Click the destination channel number. To select many channels, click the first
destination channel, then drag over all the channels where you want to paste.
4. Click the [Paste] button at the bottom of the window.
You can also copy and paste specific channel items.
After selecting the copy source in step 1, click the [Copy Details] button to display the
[Meas Channel Copy Details] dialog box.
Select the items that you want to copy.
8.8 Measurement Channels Settngs
