4-34
IM WX104-01E
Header
A header can be printed when printing the waveform or a TLOG file.
Of the items that are displayed in the file information dialog box ([Information] - [About
Document]), those that are checked are printed in the header section. For details related
to the file information, see section 4.1.
Prnt Prevew
You can preview the print layout before actually printing the data.
Selecting [File] - [Print Preview] displays the print preview screen.
Note
• The preview screen will display the print image of the specified range.
• The file information is also displayed when previewing the graph. If the color overview,
alarm, [Cursor value] window, and [Statistics] window are displayed, these are also
displayed on the preview screen along with the graph
• For the print preview operation, see the instruction manual that came with your operating
system.
Prntng
Select the printer, print range, the number of copies,
and click the [OK] button
1. Click here ([File] - [Print]).
2. The [Print] dialog box opens.
4.13 Prntng
