8-4
IM WX104-01E
8.2
Checkng the System and Intalzng Setup
Data
Checkng the System
On the Hardware Configurator of the connected CX, selecting [System Configuration]
from the [System] menu opens the [System Configuration] dialog box. You can only view
the system configuration on this [System Configuration] dialog box.
2. The [System Configuration]
dialog box opens.
1. Click [System Configuration]
on the [System] menu.
Note
If you select [System Configuration] from the [System] menu on the CX Configurator that was
opened by double-clicking the setup data file on the DAQ desktop or loading the setup data,
a [System Configuration] dialog box in which you can change the system configuration opens.
If the system configuration is changed in this dialog box and the [OK] button is clicked, a
message “System Configuration is changed Input&Data are Initialized” appears. Click the [OK]
button to initialize the data.
Intalzng the Setup Data
To initialize the settings, select [Initialize] from the [Setting] menu on the Hardware
Configurator of the CX.
2. The [Initialize]
dialog box opens.
1. Click [Initialize] on the [Setting] menu.
3. Click to complete
the initialization.
