Index
Conf
gur
ng the DX1000/DX2000
Hstorcal Trend Background
Select the background color of the historical trend display from the following:
Settings: White, Black (default setting), Cream, and Lightgray
Scroll Tme
Set the switching interval from the available settings between 5 s and 1 min. The groups
switch in ascending order.
Select whether to automatically switch on the operation display.
Jump Default Dsplay
Returns to a preset display if there is no key operation for a specific time.
Settngs
Descrpton
1min to 1h
Time until switching the display.
Off
Disables the function.
FAVORITE Key acton (Release number 3 or later)
• Acton
Settngs
Descrpton
History
The historical trend of the currently displayed data appears when you press
the favorite key.
Favorite
The displays that have been registered to the favorite key appear when you
press the favorite key. Select Favorite when you want to register displays to
the favorite key and use the key to switch between the displays.
• Group dsplay
This setting is valid when [Action] is set to [Favorite].
Settngs
Descrpton
Current
Of the displays that have been registered to the favorite key, those that
display groups (the trend, digital, bar graph, and historical trend displays) are
displayed using the currently displayed group.
Saved
Registered displays are displayed using the display groups that were selected
when they were registered.
• Tme axs zoom
This setting is valid when [Action] is set to [Favorite].
Settngs
Descrpton
Current
Historical trend displays that have been registered to the favorite key are
displayed using the current time axis zoom.
Saved
Historical trends are displayed using the time axis zooms that they were
registered with.
6.4 Enterng General Settngs
