ng the MV1000/MV2000
Use
Turn On the groups you want to use.
Group name
Set the group name. (up to 16 characters)
Channel Confguraton
Set up to 10 channels (MV2000) or 6 channels (MV1000) from measurement channels,
computation channels (/M1 and /PM1 options), and external input channels (/MC1 option,
MV2000).
Note
• The trend, digital, and bar graph displays are shown in the specified order.
• A channel can be assigned to multiple groups.
• The same channel cannot be assigned multiple times in a group.
Trp lne
Set lines at specified positions in the waveform display range on the Trend display.
• Use
Turn [ON] the trip lines you want to display.
• Poston
Set the position in the range of 0 to 100% of the display width.
• Color
The default colors are red, green, blue, and yellow. If you want to change the color,
select from the 24 available colors.
• Trend Lne
Set the line width of the trip line in dots (1 to 3).
Dsplay
7.4 Enterng General Settngs
