ng the DX1000/DX2000
6.8
Savng the Setup Data
Changed settings can be saved on the PC with the procedure below.
To send saved setup data to the connected DX1000/DX2000 and edit them, see section
6.6, “Sending the Setup data to the DX1000/DX2000.” Also, you can save stored setup
data to a memory card or other medium, and load data saved on an external storage
medium on the DX1000/DX2000 main unit.
2. The [Save As] dialog box opens.
Set the destination and
file name and click here
1. Select [File] - [Save] or [Save As].
Save
The setup data are overwritten to the preexisting file (*.PDL). The [Save As] dialog box
does not open.
Save As
Saves the setup data by specifying the save destination and file name.
Note
The CONFIG file (directly view the setup data of the DX1000/DX2000) cannot be saved using
[Save] or [Save As].
