2.2
Startng and Stoppng Data Acquston on the
DX/MV/CX, Send a Trgger
Click here (start)
Indicates that the data
acquisition is started
DX/MV/CX folder
Click here (stop)
Indicates that the data
acquisition is stopped
Startng
Clicking the start button starts the data acquisition to the internal memory of the
RECORDER.
Stoppng
When you click the stop button, a message, “Do you stop recording?” appears. Clicking
the [OK] button stops the data acquisition to the internal memory of the RECORDER.
Startng and Stoppng When Connectng the DX1000/DX2000/MV1000/
MV2000 wth the Batch Functon
If the Batch function is OFF, recording and math start simultaneously. If the Batch
function is ON, or with multibatches, recording and math start separately. When you click
the START button, the Batch Start dialog box appears allowing you to start recording and
math by individual batch, or for all batches. When you click the STOP button, the Batch
Stop dialog box appears allowing you to stop recording and math by individual batch, or
for all batches.
When the Batch Functon Is Included
Batch information
Shows the batch information set on the DX1000/DX2000/MV1000/MV2000
