Conf
gur
ng the MV1000/MV2000
• Servce port
The following table indicates the number of simultaneous uses (number of users that
can use the function simultaneously), the maximum number of connections, and the
port number for each function.
Functon
Maxmum
Number of
Connectons
Number of Smultaneous Uses
Port No.
Admnstrator
User
FTP server
2
2
2
*1
21/tcp
*3
Web server (HTTP)
1
–
–
80/tcp
*3
SNTP server
–
–
–
123/udp
*3
Modbus server
2
–
–
502/tcp
*3
Instrument
information server
–
–
–
34264/udp
*2
*1 There are user limitations. For details, see the MV1000/MV2000 Communication interface
User’s Manual (IM MV1000-17E).
*2 The port number is fixed.
*3 The default port number. You can set the value in the range of 0 to 65535. Use the default
port number unless there is a special reason not to do so.
• Status Relay
If an abnormality occurs with items turned ON, relay contact output is performed. In
the [System Configuration] screen, if [FAIL] is set to [FAIL/Alarm relay] or [FAIL/Status
relay], the [Status Relay] setting items are displayed.
Detal Settng
• Tag
Settngs
Descrpton
Tag
Displays tags. Channel numbers are displayed for channels that do not
have tags assigned.
Channel
Displays channel numbers.
• Language
Select the display language
• Decmal Pont Type
Settngs
Descrpton
Point
Sets the decimal point to a dot. Example: 1234.56
Comma
Sets the decimal point to a comma. Example: 1234,56
7.5 Enterng Basc Settngs
