6.1
Startng the Confgurator
The following two types of files can be opened using the Configurator:
CONFIG fle
This is the file located in the DX1000/DX2000 folder. It allows a direct view of the setup
data of the DX1000/DX2000. Only one CONFIG file exists in one DX1000/DX2000
folder.
You can change the setting on the Configurator, but the file cannot be saved.
Setup data fle (*.PDL)
This is the file that is saved to the PC such as to the DAQ Desktop. You can change the
settings on the Configurator and save the file and create new setup data.
The Configurator can transmit and receive the setup data, change the setup data, and
create new setup data. It can configure the following software version of DX1000/
DX2000.
DX1000/DX2000: Frmware verson 1.00 or later
Copyng the Setup Data to the DAQ Desktop
You can copy the CONFIG file to the DAQ Desktop by dragging and dropping the
CONFIG icon of the DX1000/DX2000 folder onto the DAQ Desktop.
The extension of the file that is copied becomes [PDL].
