5-19 IM WX104-01E
Conf
gur
ng the DX100/DX200/MV100/MV200
1
2
3
4
5
6
7
8
9
Index
Key Lock/Logn
Click here (also selectable from [Setting] - [SETUP [Basic] Setting]-[Setting])
Check when using login,
auto logout, and user ID.
Turn ON when using
user settings
DX100/DX200/MV200 cofiguration screen
MV100 configuration screen
Settng the key lock
• Key Lock
When using the key lock function, select whether or not to activate the key lock
function (lock or free).
• Password
Enter the password used to release the key lock using up to six characters. [???] is
displayed after the password is entered.
Settng the logn
• User name
Up to 16 characters can be entered for the user name.
• User ID
Up to 4 characters can be entered for the User ID. [???] is displayed after the
password is entered.
• Password
Up to 6 characters can be entered for the password. [???] is displayed after the
password is entered.
• Setup
Select whether or not to allow setting changes in the setup mode.
Note
• If there is a duplicate [User Name] that is turned ON, the user with the larger user number is
turned OFF.
• If [Setup] of all users that are turned ON is set to [Disable], the [Setup] of the user with the
smallest number is set to [Enable].
5.5 Confgurng the Setup Mode
