6-30 IM WX104-01E
Fle
When the multi batch function (/BT2 option; release 3 or later) is disabled
When the multi batch function (/BT2 option; release 3 or later) is enabled
Drectory name
Set the name of the directory on the storage medium for saving the data on the external
storage medium. (Up to 20 characters)
Symbols that can be used: #, %, (, ), +, -, ., @, °, and _.
Strings that cannot be used: AUX, CON, PRN, NUL, CLOCK, COM1 to COM9, and
LPT1 to LPT9.
Header
Set the header comment to be written to the data file. (Up to 50 characters)
Structure
Sets the structure of the file name when saving data.
Settngs Descrpton
Date User-assigned character string + date
Serial User-assigned character string + serial number
Batch Batch name + serial number (when using the batch function)
6.4 Enterng General Settngs
